Ethernet Cable Cross Figure Coiling Machine | TaiZheng

HS code:84798110
Model: TZ-CE400
Application:for Ethernet Cables & Coaxial Cables
Suitable materials:Cat5,Cat5e,Cat6,Cat6e,RG11,RG59 etc,
Production capacity:200 m/min
Warranty:12 months


Electric Motor Cable Wire Winders For Sale

In order to obtain a finished product which can be sold, the insulated conductors (flexible or rigid) and some small cables have to be coiled into bound coils, wrapped in plastic or shrinking foil and sometimes packed in cardboard boxes and placed on pallets.These operations can be done manually, semi-automatically or automatically.

The bigger cables with outer final sheathing are generally supplied directly on wooden reels of large dimensions.


For the production of coils of communication cable of preset length. With AC motor and frequency variator. With meter counter. The coiling system has a pneumatic brake which stops the semi auto wire winders instantaneously when reaching the preset length on the meter counter or when a fault is detected in the insulation of the cable or when pressing the STOP button. The rotating plate sets in working position each of the 2 coiling heads. During each phase of coiling, as one coiling head is rotating, the aother are remaining still, allowing the strapping or binding of the previous coil and the unloading of it. Each coiling head has a collapsible flange with a device allowing a quick and easy extraction of the coil with absolute safety.

Usually this coiler is fed by an overhead pay-off system. The ideal paying-off system is a motorized pay-off for bobbins with a built-in dancer accumulator.



Application

Suitable for coaxial cable(RG 11/6/59) & LAN cable(CAT 5/5e/6/6e) OD≤12mm

Pay-off type*

1.Passive type

2.Active type

3.Direct from extrusion line

Pay-off drum size

1.≤φ800mm

2.≤φ1250mm

Traversing type

Automatic traversing

Motor power

SIEMENS 3HP*2

Rotation speed

0-500rpm

Coils inner Diam.

200mm

Coils outer diam.

≤φ400mm

Coils width

200mm

Coil length

Standard 1000 feet for LAN cable

Daily production capacity

1000 feet(305M) per coil

350 coils per shift (8 H/D)

Typical Production Line Composition

Items No.

Name & Specification

Quantity

Remarks

01

Active Pay-off Machine

1

800-1250mm

02

Vertical Buffering Accumulator

1


03

Cross Figure Coiling Machine

1
