Views: 10 Author: Site Editor Publish Time: 2022-06-28 Origin: Site
Twister operators prefer machines that spin two or more fibers together into yarn. They handle the raw material, prepare it for processing, and use the twisting machine.
What are the applications and components of a drum twisting machine?
Applications
Applications of the drum twisting machine include:
· Wiring of round and fan-shaped power cables.
· Closure of stranded conductors.
· Assembly of fan-shaped Meriken conductors.
· Wire screening, wire armoring.
· Fiber optic stranding, wiring and insertion applications, and assembly of multi-pair telecom and special cables.
It is mainly used for large cross-section cables because it is a high speed and it can replace common types of laying machines.
Both non-metallic or metallic braiding functions and wire armoring functions are included.
Main components.
1. The whole braking process is completed by PLC through the motor inverter, air brake system, and braking resistor for overall coordinated control, with high synchronization performance and efficient braking.
2. The bifurcated payoff machine is equipped with an independent operation control cabinet, which can be operated by forwarding rotation, reverse rotation, pointing, emergency stop, bobbin tightening, and loosening. The overall payoff operation is operated by a touch screen, coordinated, and controlled by PLC. It can be operated synchronously with the winch head or fixed.
3. Non-metal wrapping machine.
Use: Mainly used for laying and winding non-woven fabric, PVC, aluminum-plastic composite tape, water stop tape, and other tapes in the outer layer of the cable.
4. Metal wrapping machine.
Use: Mainly used for steel tape armor.
5. Steel wire frame.
It uses up to 96 steel wires.
6. Rotary pneumatic crawler.
Operation mode: Forward and backward of the tractor, pointing, emergency stop, tightening, and loosening of the tracks are operated through a separate electric control cabinet. A 37KW motor drives the traction track through the gearbox to meet the required tension for traction. The tractor is operated through a human-machine interface touch screen and is coordinated, managed, and controlled by a PLC.
7. Drum head.
The running speed, direction selection, winding tension, and unwinding speed of the drum head are operated by a touch screen and controlled by PLC. It is also equipped with an independent operation cabinet to complete the hydraulic lifting platform's emergency stop, pointing, and lifting.
Suppose you need to buy a twisting machine, welcome to contact us. In that case, TaiZheng wire machine is a professional manufacturer of twisting machines to provide you with high-quality and high-efficiency equipment.
