HS code：84772090
Model：TZ-ER(45-120)
Application：Rubber cable
Suitable materials：EPR,CPE,NBR...etc
Production capacity：150 m/min（OD=6.0,T=0.8mm）
Warranty：12 months


Availability:



Inquire

Rubber Extrusion Line - Extrusion Machinery

Rubber cables offer very good electrical and mechanical properties, with an excellent resistance to abrasion, tear resistance,high temperatures, oil and chemical atmospheres.
Have a big variety of applications either in low voltage as well as medium voltage.
All of them are manufactured in Class 5 or Class 6 in order to guarantee a great flexibility.
Vulcanizing off-line by special device instead of Cured on steam atmospheres at pressures about 25 bars and temperatures up to 225 centidegree.
Equipped with feeding rolls for rubber strips and/or pellets.
Screw design(L/D)ratio(17D)optimized for processing rubber compounds.
Water cooling with temperature regulation on barrel zones and screw.
Self centering water cooling cross-heads with thermo regulation.
Rubber extrusion lines can be offered for insulating single cores conductors with EPR, (Ethylene Propylene Rubber), with or without stripe colour, or for sheathing cables with stranded cores using CPE (Rubber based with Chlorinated polyethylene)or a flame retardant low smoke compound EVA (Ethylene Vinyl Acetate)

Rubber extrusion lines

Rubber Extrusion Line Extrusion Machinery rubber Extrusion Machinery rubber extruder line

Product Message

Related Products

Industrial Silicone Plastic Cable Wire Extruder Line | TaiZheng

ABS Filament Extruder | Plastic Extrusion Machines | TaiZheng

Teflon Extruder | Wire Cable Extrusion Machine - TaiZheng

PVC Coating Extruder

Model	Screw Diam	L/D ratio	Screw Speed	Rubber Output	Main Motor
TZ-ER45	45	17:1	100 RPM	80 kg/h	15 kw
TZ-ER65	65	17:1	90 RPM	150 kg/h	45 kw
TZ-ER80	80	17:1	80 RPM	200 kg/h	60 kw
TZ-ER90	90	17:1	75 RPM	300 kg/h	75 kw
TZ-ER120	120	17:1	60 RPM	550 kg/h	150 kw

LINE COMPOSITION		EXTRUSION LINE MODEL
LINE COMPOSITION		TZ-ER45	TZ-ER65	TZ-ER80	TZ-ER90	TZ-ER120
Pay-off	Active pay-off	●	●	○	○	○
Pay-off	Passive pay-off	○	○	●	●	●
Wire straightener		●	●	●	●	●
Pre-heater		○	○	—	—	—
Powder applicator		—	—	○	○	○
Single screw extruder		●	●	●	●	●
Mold temperature controller		●	●	●	●	●
Cross-head	Self-centering	●	●	○	○	○
Cross-head	Manual adjustable	○	○	●	●	●
Granules feeding device	Hopper dryer	●	●	●	●	●
Granules feeding device	Stainless loader	○	○	○	○	○
Hot water trough	1.5m+0.5m movable	●	●	●	●	●
Printing device	Ink-jet printer	○	○	○	○	○
Printing device	Gravure printing device	●	●	●	●	●
Laser diameter gauge	X single dimensional	●	●	●	●	●
Laser diameter gauge	X-Y two dimensional	○	○	○	○	○
Cold water tough	Fixed type with air wiper	●	●	●	●	●
Industry chiller		○	○	○	○	○
Capstan	Dual wheel capstan	●	●	●	●	○
Capstan	Caterpillar	—	—	○	○	●
Accumulator		●	●	●	●	○
Length counter	Encoder type	●	●	●	●	●
Spark tester(customer-specified)		○	○	○	○	○
Oil finish device		○	○	○	○	○
Take-up	Dual bobbin use	●	●	●	●	●
Take-up	Single bobbin use	○	○	○	○	○
Line control system	HMI	●	●	●	●	●
Line control system	HMI+IPC	○	○	○	○	○
Remarks		● Standard/○ Optional/ —None

Model	Screw Diam	L/D ratio	Screw Speed	Rubber Output	Main Motor
TZ-ER45	45	17:1	100 RPM	80 kg/h	15 kw
TZ-ER65	65	17:1	90 RPM	150 kg/h	45 kw
TZ-ER80	80	17:1	80 RPM	200 kg/h	60 kw
TZ-ER90	90	17:1	75 RPM	300 kg/h	75 kw
TZ-ER120	120	17:1	60 RPM	550 kg/h	150 kw

LINE COMPOSITION		EXTRUSION LINE MODEL
LINE COMPOSITION		TZ-ER45	TZ-ER65	TZ-ER80	TZ-ER90	TZ-ER120
Pay-off	Active pay-off	●	●	○	○	○
Pay-off	Passive pay-off	○	○	●	●	●
Wire straightener		●	●	●	●	●
Pre-heater		○	○	—	—	—
Powder applicator		—	—	○	○	○
Single screw extruder		●	●	●	●	●
Mold temperature controller		●	●	●	●	●
Cross-head	Self-centering	●	●	○	○	○
Cross-head	Manual adjustable	○	○	●	●	●
Granules feeding device	Hopper dryer	●	●	●	●	●
Granules feeding device	Stainless loader	○	○	○	○	○
Hot water trough	1.5m+0.5m movable	●	●	●	●	●
Printing device	Ink-jet printer	○	○	○	○	○
Printing device	Gravure printing device	●	●	●	●	●
Laser diameter gauge	X single dimensional	●	●	●	●	●
Laser diameter gauge	X-Y two dimensional	○	○	○	○	○
Cold water tough	Fixed type with air wiper	●	●	●	●	●
Industry chiller		○	○	○	○	○
Capstan	Dual wheel capstan	●	●	●	●	○
Capstan	Caterpillar	—	—	○	○	●
Accumulator		●	●	●	●	○
Length counter	Encoder type	●	●	●	●	●
Spark tester(customer-specified)		○	○	○	○	○
Oil finish device		○	○	○	○	○
Take-up	Dual bobbin use	●	●	●	●	●
Take-up	Single bobbin use	○	○	○	○	○
Line control system	HMI	●	●	●	●	●
Line control system	HMI+IPC	○	○	○	○	○
Remarks		● Standard/○ Optional/ —None
